![430-450 MHz Antenna](../assets/images/am5_430_450sm.gif) 430-450 MHz. UHF ANTENNA Model Number
- HS6-43050 (6 dBd)
- HD9-43050 (9 dBd)
- Gain: 6 dBd, 9 dBd
- Bandwidth: 20 MHz.
- V.S.W.R.: 1.5:1
- Polarization: Vertical
- Power Rating: 400 Watts Maximum
- Termination: Type N Female
- Vertical Aperture (3 dB from max.)
- 15 degrees (6 dBd)
- 7 degrees (9 dBd)
- Weight: 13.7 lb.
- Wind Load (Lateral thrust @ 100 mph): 92 lb.
- Wind Area (flat plate equivalent): 1.2 sq. ft.
- Maximum Wind Speed: 130 mph
- Material Feed Lines: Copper
- Radiators: Copper
- Color Radome: White Fiberglass
- Mounting: Galvanized steel mounting clamps permit mounting the antenna to a support pipe up to 3.25" O.D.
- Lightning Protection: Direct Ground
|
